$3,694.00
All-Star medical strives to stock products that are HSA/FSA Eligible. Learn more.
The All New Jazzy Evo 613/613i has two battery options, lead acid and lithium ion. The EVO has a 300 lb. capacity and a top speed of 5.1 mph. The 13 inch drive wheels allow a 3 inch ground clearance.
The 35 AH Lithium Batteries (17 lbs.) has a 21 mile range for someone who’s 200 lb. and 17.6 mile range for someone who’s 300 lbs.The U-1 (50.4 lbs.) batteries have a 17.9 mile range for someone who’s 200 lb. and 14.4 mile range for someone who’s 300 lbs.You will be able to choose from 6 color options and the adjustable seat sizes: 16×16 | 18×18 | 20×18
| CATEGORY | SPECIFICATION |
|---|---|
| Model |
Jazzy® EVO 613/ Jazzy® EVO 613 Li
|
| Weight Capacity | 300 lbs. |
| Turning Radius3 | 22″ |
| Width3 | 22″ |
| Length3 | 41″ w/footplate 35″ w/o footplate |
| Maximum Speed2 | Up to 5.1 mph |
| Ground Clearance3 | 3″ at motor bracket |
| Front Wheels | 5″ solid |
| Drive Wheels | 13″ solid |
| Rear Wheels | 5″ casters |
| Drivetrain | Two motor, in-line, mid-wheel drive |
| Braking System | Regenerative and electro-mechanical |
| Suspension Type | Active-Trac® (ATX) |
| Standard Seat Sizes | High-back Black vinyl 16″x16″-18″, 18″x18″-20″, 20″x18″-20″ |
| Seat-to-Floor Range | 19.75″-21.25″ |
| Seat Weight(s)3 | 46 lbs. (16″), 48 lbs (18″), 50 lbs. (20″) |
| Maximum Seat Size | 20″-20″ |
| Power Elevating Seat | NA |
| Standard Electronics | 40A, PG GC3 |
| Battery Size(s)4 | (2) 12 volt, U-1 or (1) 25V Lithium-iron phosphate |
| Battery Weight6 | (2) U1-23.5 lbs. each; (1)Lithium – 18.5 lbs. |
| Battery Charger | 3.5A, off-board |
| Per Charge Range2,3,5 | SLA- up to 14 miles (300 lbs.), up to 17.1 miles (200lbs,); Lithium up to 17.6 miles ( 300 lbs.), up to 21 miles (200lbs.) |
| Weight of Heaviest Piece7 | 94 lbs. (base) |
| Total Weight | 189 lbs. . (SLA); 160.5 (Lithium) |
| HCPCS Code | Group 2: Standard (K0822/K0823) |
| Warranty | Frame: 5-year limited; Drivetrain: 13-month limited; Electronics: 13-month limited; Batteries: 13-month limited (SLA); 3-year limited (Lithium) |
| Colors | Black (matte), White (matte), Red (matte), Iceberg Blue (matte), Robin’s Egg Blue (matte), Sugar Plum (matte) |
| Weight | 165.5 lbs |
|---|---|
| Warranty Infomation | Frame: 5-year limited; Drivetrain: 13-month limited; Electronics: 13-month limited; Batteries: 13-month limited (SLA); 3-year limited (Lithium) |
