* Pride FDA Class II Medical Devices are designed to aid individuals with mobility impairments.
|Drive Wheels||10″ Pneumatic (Standard)
10″ Solid (Optional)
|Caster Wheels||Front: 5″ Solid
Rear: 6″ Solid
|Maximum Speed*||Up to 4 mph|
|Ground Clearance||2.25″ (battery trail rail)|
|Turning Radius||21.25″ without front riggings|
|Overall Length||34.5″ without front riggings|
|Seating Sizes: Synergy/Static||TRU-Balance 2: Width 10″ – 20″ Depth 10″ – 20″|
|Seating Sizes: Power Tilt||TRU-Balance 2: Width 14″ – 20″ Depth 14″ – 20″|
|Seat-to-Floor Heights: Synergy/Static||TRU-Balance 2: 16.5″ – 17.5″1,2|
|Seat-to-Floor Heights: Power Tilt||TRU-Balance 2: 16.875″1,2,3|
|Available with Manual Tilt and Recline||Yes4|
|Standard Battery Size||U-15|
|Battery Weight||24.5 lbs.6|
|Available Electronics||70A Q-Logic NE
70A Q-Logic NE+
70A Q-Logic EX
All Quantum Rehab® units can be ordered with specialty controls
|Standard Charger||5A Off-board|
|Weight Capacity||300 lbs.3,7|
|Base Weight||104.5 lbs.|
|Colors||Candy Apple Red, Viper Blue|
|Medicare Code Coverage||Group 2:
Single Power (K0835)
|Notes||1All measurements +/- 1/8″ with 18″ x 18″ seat, fixed towers, 300 lbs. weight capacity and solid tires (add 3/8″ with pneumatic tires). Widths may increase seat-to-floor height. Contact Customer Service for details. Listed measurements are in the lowest position; does not include elevating system unless specified.
2Power Recline and Power Front Riggings do not increase seat-to-floor height.
3250 lbs. weight capacity with TRU-Balance® Systems
4The Synergy® Manual Tilt weight capacity is 75 lbs. and maximum dimensions are 14″W x 14″D. Maximum dimensions of the Manual Recline vary by power base and seating system.
5Battery capacity may change when adding power positioning systems.
6Battery weight may vary based on manufacturer.
7Weight capacity is dictated by the selection of seating.
Lifetime limited warranty on frame;
13-month warranty on electronics;
13-month warranty on drive motor
